DEYE 80KW HYBRID INVERTER HV P3 (SUN-80K-SG02HP3-EU-EM6)

DEYE 80KW HYBRID INVERTER HV P3 (SUN-80K-SG02HP3-EU-EM6)

R109000,00 EXCL. VAT

Deye SUN-80K-SG02HP3-EU-EM6: 80kW three-phase hybrid inverter with 6 MPPTs, high-voltage battery support (160–1000V), 160kW PV input, and 160A charge/discharge.

PAY USING EFT AND SAVE ON BANK FEES

The Deye SUN-80K-SG02HP3-EU-EM6 is a heavy-duty three-phase hybrid inverter designed for large commercial and industrial solar energy systems. With high-voltage battery compatibility, massive PV input capacity, and intelligent AC/DC coupling, this inverter delivers unmatched energy flexibility and performance.

Technical Highlights:

Rated Output Power: 80,000W

Max. PV Input Power: 160,000W

MPPT Trackers: 6 MPPTs with 2 strings per tracker (6/2+2+2+2+2+2)

Max. PV Input Voltage: 1,000V

MPPT Operating Range: 150–850V

Start-Up Voltage: 180V

Rated PV Input Voltage: 650V

Max. PV Input Current: 324A total (54A per tracker)

Max. PV Short-Circuit Current: 396A total (66A per tracker)

Battery Compatibility: High-voltage lithium-ion (160–1000V)

Battery Inputs: 2

Max. Charging / Discharging Current: 160A (80A + 80A)

AC Output Voltage: 3-phase 220/380V or 230/400V

Rated AC Output Current: 121.3A

Max. AC Output Current: 133.4A

Unbalanced Output Support: Yes – 100% per phase supported

AC Passthrough (Grid to Load): 200A

Peak Power (Off-Grid): 1.5× rated power for 10 seconds

Power Factor Adjustment: 0.8 leading to 0.8 lagging

Efficiency:

Max Efficiency: 97.6%

Euro Efficiency: 97.0%

MPPT Efficiency: >99%

THD: <3% (of nominal power)

DC Injection: <0.5% In

Monitoring & Communication:

Display: LCD with real-time performance feedback

Interfaces: RS485, RS232, CAN

Monitoring Options: GPRS / Wi-Fi / Bluetooth / 4G / LAN (optional)

Battery Scheduling: 6 programmable time periods

Parallel Support: Up to 10 units supported (on-grid and off-grid)

AC Coupling & Generator Integration: Yes

Protection Features:

Integrated DC Type II and AC Type II surge protection

Reverse polarity, short circuit, overcurrent, insulation monitoring, and anti-islanding protection

Certifications: IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, G98, G99, VDE-AR-N 4105

Physical Specs:

Dimensions: 606 × 927 × 314 mm

Weight: 97.5 kg

Cooling: Intelligent air cooling

Noise Level: ≤65 dB

Ingress Protection: IP65 (suitable for indoor/outdoor use)

Operating Temperature Range: -40°C to +60°C (derates above 45°C)

Altitude Limit: 3000 m

Mounting: Wall-mounted

Warranty: 5 years standard (10 years optional depending on installation site)

The SUN-80K-SG02HP3-EU-EM6 is a commercial-grade powerhouse that provides exceptional performance, scalability, and full-featured hybrid energy control for the most demanding environments.
