DEYE 50KW HYBRID INVERTER HV P3 (SUN-50K-SG01HP3-EU-BM4)

The Deye SUN-50K-SG01HP3-EU-BM4 is a powerful three-phase high-voltage hybrid inverter tailored for large-scale commercial and industrial applications. Designed to handle massive energy throughput, this inverter supports high-voltage lithium batteries, parallel operation, and complete smart load, generator, and AC/DC coupling integration.

Technical Highlights:

Rated Output Power: 50,000W

Max. PV Input Power: 65,000W

MPPT Trackers: 4 MPPTs with 4 strings total (4/1+1+1+1)

Max. PV Input Voltage: 1000V

MPPT Operating Range: 150–850V

Start-Up Voltage: 180V

Rated PV Input Voltage: 600V

Full Load DC Voltage Range: 450–850V

Max. PV Input Current: 144A total (36A per MPPT)

Max. PV Short-Circuit Current: 220A total (55A per MPPT)

Battery Compatibility: High-voltage lithium-ion (160–800V)

Number of Battery Inputs: 2

Max. Charging / Discharging Current: 100A (50A + 50A)

AC Output Voltage: 3-phase 220/380V or 230/400V

Rated AC Output Current: 75.8A

Max. AC Output Current: 83.4A

Max. Unbalanced Output (per phase): 75.8A

AC Passthrough (Grid to Load): 200A

Peak Power (Off-Grid): 1.5× rated power for 10 seconds

Power Factor Adjustment: 0.8 leading to 0.8 lagging

Generator Input / Smart Load / AC Coupling: 75.8 / 200 / 75.8A

Efficiency: Max 97.6% | Euro Efficiency: 97.0% | MPPT Efficiency 99.9%

Monitoring & Communication:

Display: LCD with live system data

Interfaces: RS485, CAN

Monitoring Options: Wi-Fi / LAN / Bluetooth / GPRS / 4G (optional)

Battery Management: 6 configurable time periods for charge/discharge

Parallel Support: Multi-unit parallel support available (Q1 2023 onwards)

AC Coupling & Generator Support: Yes

Protection Features:

Integrated Type II surge protection (DC & AC)

Reverse polarity, overcurrent, short circuit, insulation, ground fault, and anti-islanding protection

Certifications: VDE 4105, IEC 61727, IEC 62116, AS4777.2, CEI 0-21, EN 50549-1, G98, G99, C10-11

Physical Specs:

Dimensions: 527 × 894 × 294 mm

Weight: 75 kg

Cooling: Intelligent active cooling

Noise Level: ≤65 dB

IP Rating: IP65 (indoor/outdoor)

Operating Temperature Range: -40°C to +60°C (derates above 45°C)

Mounting: Wall-mounted

Warranty: 5 years standard (10 years optional depending on region)

The SUN-50K-SG01HP3-EU-BM4 delivers industry-leading hybrid functionality, robust power handling, and high-efficiency energy control, making it a top choice for large-scale energy storage systems.
