CHINT EARTH LEAKAGE 80A 6KA 30MA

Product Name: CHINT Earth Leakage Circuit Breaker 80A 6kA 30mA (Model: NL1-100-4P-080-30mA)

Product Information and Technical Details:

Model: NL1-100-4P-080-30mA

Type: Earth Leakage Circuit Breaker (ELCB)

Current Rating: 80A (Amperes)

Breaking Capacity: 6kA (kiloamperes)

Sensitivity: 30mA (milliamperes)

Configuration: 4P (Four Poles)

Application: The CHINT Earth Leakage Circuit Breaker is designed for professional use in electrical systems to protect against electric shock and prevent electrical fires by quickly disconnecting the power supply when it detects a ground fault or leakage current.

Key Technical Information:

Current Rating: The ELCB has a current rating of 80A, indicating the maximum current it can handle.

Breaking Capacity: With a breaking capacity of 6kA, this ELCB can safely interrupt fault currents within its rated capacity, preventing electrical fires and equipment damage.

Sensitivity: The device is sensitive to ground fault or leakage currents as low as 30mA, making it effective in detecting even minor electrical faults.

Configuration: It is a 4P ELCB, capable of disconnecting power in all four live conductors, providing comprehensive protection.

Operation: The ELCB is designed to trip (open the circuit) when it detects a ground fault, thus protecting against electrical accidents and fire hazards.

Installation: Professional electricians are typically responsible for installing the CHINT Earth Leakage Circuit Breaker. Proper installation is essential for safety and the correct operation of the device.

Usage: To use the ELCB, connect it to the electrical circuit where protection is needed, ensuring it is appropriately rated for the load. The ELCB continuously monitors the current flow and disconnects the power supply if it detects a leakage current, thus safeguarding people and property from electrical hazards.

For comprehensive instructions and precise technical specifications, consult the product datasheet or adhere to the manufacturer’s guidelines.
