CHINT CIRCUIT BREAKER C-CURVE 80A 6KA

Product Name: CHINT Circuit Breaker C-Curve 80A 6kA (Model: DZ158-4P-C080-06)

Product Information and Technical Details:

Model: DZ158-4P-C080-06

Type: Circuit Breaker

Current Rating: 80A (Amperes)

Breaking Capacity: 6kA (kiloamperes)

Trip Curve: C-Curve

Configuration: 4P (Four Poles)

Application: The CHINT Circuit Breaker is designed for professional use in electrical systems to protect circuits and equipment by quickly interrupting the electrical supply in response to overcurrent conditions, with a C-curve tripping characteristic.

Key Technical Information:

Current Rating: The circuit breaker has a current rating of 80A, indicating the maximum current it can handle.

Breaking Capacity: With a breaking capacity of 6kA, this circuit breaker can safely interrupt fault currents within its rated capacity, preventing electrical fires and equipment damage.

Trip Curve: The C-curve signifies the response characteristic of the circuit breaker. C-curve breakers trip relatively quickly in response to moderate overcurrent conditions.

Configuration: It is a 4P circuit breaker, designed to provide protection across all four live conductors, offering comprehensive circuit protection.

Operation: The circuit breaker will trip (open the circuit) in response to overcurrent conditions that exceed its rated settings, thus protecting connected devices and wiring.

Installation: Professional electricians typically handle the installation of the CHINT Circuit Breaker. Proper installation is essential for safety and the correct operation of the device.

Usage: To use the circuit breaker, connect it to the electrical circuit where overcurrent protection is needed, ensuring it is appropriately rated for the load. The breaker will trip when it detects overcurrent conditions, safeguarding against electrical damage and hazards.

For comprehensive instructions and precise technical specifications, consult the product datasheet or adhere to the manufacturer’s guidelines.
